BD Sensors 26600GX102R35100N401008 Pressure Transmitter

Product Code: 26600GX102R35100N401008

  • Ceramic sensor with 0-10 V output
  • High accuracy at 0.5% FSO
  • Wide temp range: -40 to 125°C
  • Robust shock resistance: 500 g/1 ms
  • Fast response time of 3 ms
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pressure Transmitter
Brand BD SENSORS
Series 26.600 G
Accuracy 0.5% FSO
Application Mechanical and plant engineering. General industrial applications.
Electrical Connection Male and Female Plug ISO 4400
Mechanical Stability Vibration: 10 g, 25 Hz ... 2 kHz according to DIN EN 60068-2-6. Shock: 500 g / 1 msec according to DIN EN 60068-2-27.
Mechanical Connection 1/2 in NPT
Mechanical Life 10000000 Operations
Operational Life 100 million load cycles
Operational Temperature -40 to 125 deg C
Output Type 0-10 V
Response Time <=3 ms
Seal Material FKM
Shock Resistance 500 g/1 ms
Standards and Approvals CE, cULus, REACH, RoHS
Version Oil and grease free

Description

<p>The 26.600 G series ceramic sensor is a reliable choice for professionals in the industrial and commercial sectors seeking precision and durability. Designed to deliver consistent performance, this sensor offers an output type of 0-10 V, ensuring compatibility with a wide range of applications where voltage-based outputs are essential.</p><p>One of the standout features of this product is its accuracy, rated at 0.5% FSO (Full Scale Output). This level of precision makes it suitable for tasks requiring meticulous measurements and control, giving you confidence in its performance across various operational scenarios.</p><p>With an operational temperature range spanning from -40 to 125 degrees Celsius, the 26.600 G series ceramic sensor is built to withstand extreme environmental conditions typical in demanding industrial settings. Whether you&amp;#39;re dealing with harsh winter environments or high-temperature processes, this sensor maintains functionality without compromise.</p><p>In terms of compliance and safety standards, this product meets CE, cULus, REACH, and RoHS approvals. These certifications ensure that it adheres to international safety regulations and environmental directives—an important consideration for businesses looking to maintain high standards in their operations.</p><p>Durability is further enhanced by its impressive shock resistance capability; it can withstand up to 500 g/1 ms shocks. This robustness makes it ideal for installations where mechanical stress might be a concern. Additionally, the mechanical life extends up to ten million operations—highlighting its long-term reliability even under continuous use.</p><p>Installation flexibility is provided through its mechanical connection via a 1/2 inch NPT fitting—a common standard that simplifies integration into existing systems. The electrical connection features both male and female plugs conforming to ISO 4400 standards, ensuring secure connectivity that minimizes downtime due to electrical issues.</p><p>For rapid response requirements, the sensor boasts a response time of less than or equal to three milliseconds—ensuring quick adaptation to changes within your system&amp;#39;s parameters. This responsiveness can be crucial in applications where timing is critical for maintaining process efficiency.</p><p>Finally, the seal material made from FKM provides excellent chemical resistance and durability against aggressive substances often encountered in industrial environments—further extending the lifespan of your equipment by protecting internal components from potential damage.</p><p>Overall, the combination of accuracy, robust construction, extensive operational range, compliance with key industry standards—and ease-of-installation make this ceramic sensor a sound investment for those needing dependable performance over time without sacrificing quality or safety considerations.</p>
