Specifications

Dimensions (mm)	54W x 90H x 65D
Nominal Voltage DC (V)	70
Nominal Discharge Current (8/20µs) - In (kA)	40
Operational Temperature Range (°C)	-40 to 80
Reference No.	918420
SPD Type	1
Suitable For	Pluggable DIN Rail Mounted
Voltage Protection Level - Up (kV)	350
Weight (kg)	0.212
Nominal Load Current AC - I? (A)	12
Enclosure Material	Thermoplastic, UL 94 V-0
Nominal Voltage (V)	70
Mounting Method	DIN rail (top hat rail) 35 mm
Earth Fault Protection	Separate conductor
Maximum Continuous Voltage DC (V)	75
Voltage Protection Level Earth	350
Limiting Frequency (Hz)	1
L-L Capacitance (nF)	≤ 2
L-PE Capacitance (nF)	≤ 2
Voltage Protection Level - Up (V)	Line-Line for In C2: ≤ 400 Line-PG for In C2: ≤ 400 Line-Line at 1 kV/µs C3 ≤ 350 Line-PG at 1 kV/µs C3 ≤ 350
Lightning Impulse Current (10/350 µs) - Iimp (kA)	7
Maximum Continuous Operating Voltage MCOV DC (V)	75
Product Type	Combined Lightning Current and Surge Arrester
Brand	DEHN
Capacitance	<=2 nF (L-L), <=2 nF (Line-PG)
Colour	Red
Cross Section	0.5-6 sq-mm Solid, 0.5-4 sq-mm Flexible
Degree of Protection	IP20
Depth	65 mm
Height	90 mm
Lightning Impulse Current	3.5 kA (Per Line), 7 kA (Total)
Material	Thermoplastic
Mounting Type	35 mm DIN Rail
Operational Temperature	-40 to 80 deg C
Rated Current	20 kA (Per Line), 40 kA (Total)
Rated Voltage	75 VDC
SPD Class	Type 1
Standards and Approvals	IEC 61643-21, EN 61643-21
Voltage Protection Level	<=400V (L-L) for In C2), <=400V (Line-PG) for In C2), <=350V (L-L) at 1 kV/µs C3), <=350V (Line-PG) at 1 kV/µs C3)
Weight	212 g
Width	54 mm
