Specifications

Dimensions (mm)	27W x 90H x 65D
Nominal Voltage DC (V)	36
Nominal Discharge Current (8/20µs) - In (kA)	40
Operational Temperature Range (°C)	-40 to 80
Reference No.	918421
SPD Type	1
Suitable For	Pluggable DIN Rail Mounted
Voltage Protection Level - Up (kV)	48
Weight (kg)	0.118
Nominal Load Current AC - I? (A)	0.05
Enclosure Material	Thermoplastic, UL 94 V-0
Nominal Voltage (V)	36
Mounting Method	DIN rail (top hat rail) 35 mm
Earth Fault Protection	Separate conductor
Maximum Continuous Voltage DC (V)	36.8
Voltage Protection Level Earth	600
Limiting Frequency (Hz)	1
L-L Capacitance (nF)	≤ 1
Voltage Protection Level - Up (V)	Line-Line for In C2: ≤ 65 Line-PG for In C2: ≤ 800 Line-Line at 1 kV/µs C3 ≤ 48 Line-PG at 1 kV/µs C3 ≤ 600
L-L Capacitance (pF)	≤ 10
Lightning Impulse Current (10/350 µs) - Iimp (kA)	7
Maximum Continuous Operating Voltage MCOV DC (V)	36.8
Product Type	Combined Lightning Current and Surge Arrester
Brand	DEHN
Capacitance	<=1 nF (L-L), <=10 nF (Line-PG)
Colour	Yellow
Cross Section	0.5-6 sq-mm Solid, 0.5-4 sq-mm Flexible
Degree of Protection	IP20
Depth	65 mm
Height	90 mm
Lightning Impulse Current	3.5 kA (Per Line), 7 kA (Total)
Material	Thermoplastic
Mounting Type	35 mm DIN Rail
Operational Temperature	-40 to 80 deg C
Rated Current	20 kA (Per Line), 40 kA (Total)
Rated Voltage	36.8 VDC
SPD Class	Type 1
Standards and Approvals	IEC 61643-21, EN 61643-21
Voltage Protection Level	<=65V (L-L) for In C2), <=800V (Line-PG) for In C2), <=48V (L-L) at 1 kV/µs C3), <=600V (Line-PG) at 1 kV/µs C3)
Weight	118 g
Width	27 mm
