Novaris SFD1-6-10-50-C Combined Power Signal Protector 2-P 1 PH 10 kA Power 20 kA Signal 40VAC 50/60 Hz TS35 116mmH IP20

Product Code: SFD1-6-10-50-C

  • Surge Filter for 40 VAC systems
  • High surge capacity: 10 kA Power, 20 kA Signal
  • Compact size: 18mm W x 116mm H x 70mm D
  • DIN Rail mountable on TS35
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 116H x 18W x 70D
Maximum Continuous Operating Voltage MCOV AC (V) 50
Maximum Discharge Current (8/20µs) - Imax (kA) 10
No. of Phases 1
Nominal Voltage AC (V) 40
Operational Temperature Range (°C) -40 to 85
Voltage Protection Level (3kA 8/20µs) - Up (kV) <0.18
Maximum Load Current - I? (A) 6
Product Type Combined Power and Signal Protector
Brand NOVARIS
Series SFD-C
Connection Type Series
Degree of Protection IP20
Depth 70 mm
Height 116 mm
Humidity 5-95%
Modes of Protection L-N, L-PE, N-PE
Mounting Type TS35 DIN Rail
Number of Poles 2
Operational Temperature -40 to 85 deg C
Phase 1
Rated Current 10 kA Power, 20 kA Signal
Rated Frequency 50/60 Hz
Rated Voltage 40 VAC
Standards and Approvals IEC 61643-11, AS/NZS 1768, IEEE C62.41, IEC 1000-4-5, IEC 61643-21
Tightening Torque 0.5 N-m
Voltage Protection Level <180 V
Weight 200 g
Width 18 mm

Description

COAX+Power combined protectors with a nominal voltage of 40VAC and maximum continuous voltages of 50VAC (power) and 8.2V (signal). It has a maximum discharge current of 10 kA (power) and 20kA (signal) with a maximum load current of 6A. The voltage protection level is &lt;180V at 3 kA (8/20 ms) in series connection. This protector is ideal for security and CCTV camera protection on DIN rail, with an IP20 rating.
