ABB CA431E Auxiliary Contact Block 4P 24-690VAC

Product Code: CA431E

  • Clip-On accessory for easy installation
  • Handles 24-690 VAC, 4 A current
  • Front fastening with screw terminals
  • Complies with IEC/EN and UL standards
  • Compatible with AF09-AF80 models
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Auxiliary Contacts 3NO/1NC
Dimensions (mm) 43W x 43H x 39.5D
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) 690
Rated Impulse Withstand Voltage (kV) 6
Rated Operational Voltage AC (V) 24 - 690
Suitable For AF09 - AF80
Rated Operational Current AC-15 230V (A) 4
No. of Normally-open Contacts 3
No. of Normally-closed Contacts 1
Product Type Auxiliary Contact Block
Brand ABB
Connection Type Screw Terminal
Contact Configuration 1NC+3NO
Depth 39.5 mm
Height 43 mm
Model Clip-On
Mounting Type Front Fastening
Number of Poles 4
Rated Current 4 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 6 kV
Rated Insulation Voltage 690 V
Rated Voltage 24-690 VAC
Standards and Approvals IEC/EN 60947-5-1, UL 60335-2-40 LZGH2 A2L, UL 60947-5-1, CSA C22.2 No. 60335-2-40 LZGH2 A2L, CSA C22.2 No. 60947-5-1-14
Suitable For Use With AF09-AF80
Terminal Type Screw
Width 43 mm

Description

CA4-31E is a 4-pole front mounted auxiliary contact block equipped with screw terminals. CA4-..E version offers terminal assortment matching the marking of 3-pole AF26(Z)(B)..96-30-00, AF40..96-30-11, AFC26..38-30-00, 4-pole AF09(Z)(B)..80-40-00 / AFC09..38-40-00 or AF09(Z)(B)..80-22-00 / AFC09..38-22-00 contactors. CA4-31E is available with 3 N.O. and 1 N.C. instantaneous contacts for standard industrial environments.
