ABB MCB-10 Single Contact Block 1NO 690V Front Mount 1NO Plastic

Product Code: MCB-10

  • Illuminated accessory with yellow dome
  • High protection: IP67, IP69K rated
  • Operates in -25 to 80°C environments
  • Durable ABS chrome plated front ring
  • Fits 22.3 mm flange mount hole
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Single Contact Block
Brand ABB
Ambient Temperature -25 to 80 deg C
Degree of Protection IP67, IP69K
Diameter 44.5 mm
Dome Colour Yellow
Dome Diameter 26 mm
Dome Height 2 mm
Dome Material PA-12
Front Ring Material ABS, Chrome Plated
Gross Weight 30 g
Illumination Illuminated
Installation Conditions Arbitrarily
Lamp Colour Yellow
Mounting Hole Diameter 22.3 mm
Mounting Type Flange
Shape Round, Flat Dome
Shock Resistance 30 g/ms
Standards and Approvals EN IEC 60947-1, EN IEC 60947-5-1
Tightening Torque 0.6 N-m
Vibration Resistance 10-150 Hz

Description

<p>This accessory is a robust and reliable component designed for industrial and commercial applications, offering both functionality and durability. With its illuminated feature, it ensures visibility in various conditions, making it suitable for environments where clarity is essential.</p><p>The product boasts a tightening torque of 0.6 N-m, ensuring secure installation without the risk of over-tightening. Its degree of protection is impressive, rated at IP67 and IP69K. This means it can withstand dust ingress and high-pressure water jets from any direction—ideal for challenging industrial settings that demand resilience against harsh elements.</p><p>It adheres to stringent standards with approvals under EN IEC 60947-1 and EN IEC 60947-5-1, assuring compliance with international safety regulations. The ambient temperature range between -25 to 80 degrees Celsius highlights its versatility across diverse climates, whether it&amp;#39;s the cooler southern regions or the warmer northern areas of Australia.</p><p>Mounting this accessory is straightforward due to its flange mounting type, compatible with a mounting hole diameter of 22.3 mm. The round flat dome shape not only provides an aesthetic appeal but also contributes to ease of use in tight spaces.</p><p>Durability extends beyond environmental resistance; vibration resistance from 10-150 Hz ensures stability in dynamic settings while shock resistance up to 30 g/ms protects against sudden impacts. These features are crucial for maintaining operational integrity in fast-paced industrial environments.</p><p>The front ring material combines ABS with chrome plating, offering both strength and a sleek finish that resists wear over time. At a gross weight of just 30 grams, it adds minimal load while delivering maximum performance.</p><p>Installation flexibility is another highlight as it&amp;#39;s designed for arbitrary positioning—giving you freedom during setup without compromising on functionality or safety.</p><p>With dimensions carefully considered—the dome color being yellow enhances visibility while the dome diameter measures at 26 mm complemented by a height of just 2 mm—it integrates seamlessly into existing systems without obstructive bulkiness.</p><p>Constructed from PA-12 material known for its excellent mechanical properties such as toughness and fatigue resistance alongside dimensional stability even under fluctuating temperatures makes this product highly dependable over prolonged use periods.</p><p>Overall diameter stands at a compact yet effective size of 44.5 mm allowing easy integration into various setups whilst ensuring prominent illumination through its yellow lamp feature aiding operational efficiency especially where visual alerts play critical roles within system operations or user interactions alike.</p>
