ABB ESB4030N06 Installation Contactor 3P 40A 3.7kW 400VAC Screw DIN Rail Mount

Product Code: ESB4030N06

  • Compatible with 400 VAC systems
  • Supports 40 A current capacity
  • Operates on AC/DC voltage types
  • Secure screw terminal connections
  • Compact DIN rail mounting design
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Poles 3
Operational Temperature Range (°C) -25 to +55
Pollution Degree 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) 500
Rated Control Circuit Voltage AC/DC (V) 230
Rated Impulse Withstand Voltage (kV) 6
Rated Operational Current (A) 40
Rated Operational Current AC-3 230V (A) 22 (NO)
Rated Operational Voltage DC (V) 220
Rated Operational Power AC-3 230V (kW) 3.7 (NO)
Rated Operational Voltage AC (V) 400
Dimensions (mm) 54W x 85H x 65D
Rated Operational Current AC-1 (A) 40 (NO)
No. of Modules - Width 17.5 mm 3
Width in Number of Modular Spacings 3
No. of Normally-open Contacts 3
Built-in Depth (mm) 58
Rated Control Circuit Voltage (V) 230
Excitation Voltage Type AC/DC
Hum-free Yes
Product Type Installation Contactor
Brand ABB
Series ESB
Contact Configuration 3NO
Degree of Pollution IP3
Degree of Protection IP20
Depth 65 mm
Height 85 mm
Mounting Type DIN Rail
Number of Modules 3
Number of Poles 3
Operating Voltage Type AC/DC
Operational Temperature -25 to 55 deg C
Rated Current 40 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 6 kV
Rated Insulation Voltage 500 V
Rated Power 3.7 kW
Rated Voltage 400 VAC
Terminal Type Screw
Utilisation Category AC-1 According to EN IEC 60947-4-1
Width 54 mm

Description

The ESB40..N installation contactors are used to control single and three-phase loads up to 40 A and can be operated by AC or DC. These contactors are made for use in household applications as well as in industrial environments. The following benefits are provided: Hum-free operation, low power consumption and integrated overvoltage protection. Various contact combinations and accessories are available.
