ABB MCRA004ATN Mini Contactor Relay 220-240V 4NC 50/60Hz

Product Code: MCRA004ATN

  • Compact mini contactor for AC applications
  • Operates at 220-240 V with 6 A current
  • IP20 protection, DIN rail mounting
  • Screw terminals ensure secure connections
  • Withstands up to 6 kV impulse voltage
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Poles 4
Operating Voltage DC (V) 440
Operating Voltage AC (V) 690
Rated Control Supply Voltage AC (V) 220
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) 750
Rated Impulse Withstand Voltage (kV) 6
Rated Control Circuit Voltage AC (V) 220 - 240
Rated Operational Current (A) 6
Rated Operational Current AC-15 240V (A) 6
Rated Operational Voltage AC (V) 690
Auxiliary Contacts 4NC
Dimensions (mm) 45W x 48H x 56D
Rated Supply Voltage AC (V) 220
Rated Operational Current AC-15 400V (A) 4
No. of Normally-closed Auxiliary Contacts 4
Product Type Mini Contactor Relay
Brand ABB
Series M
Actuating Voltage Type AC
Connection Type Screw Terminal
Contact Configuration 4NC
Degree of Protection IP20
Depth 56 mm
Height 48 mm
Mounting Type DIN Rail
Number of Poles 4
Operating Voltage Type AC
Operational Temperature -40 to 70 deg C
Power Loss 0.4 W
Rated Current 6 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 6 kV
Rated Insulation Voltage 750 V
Rated Voltage 220-240 V
Short Circuit Protective Devices 10 A, Fuse Type gG
Terminal Type Screw
Width 45 mm

Description

The MCRA004ATN mini contactor relay is a dimension optimized 4 pole contactor relay with screw terminals. This device is a great solution when high performances are needed but the space is limited. Mini contactors are used in residential buldings, commercial buildings and industrial applications for switching of control signals up to 6 A / 240 V (AC-15). The product is suitable for wall or rail mounting.
