Specifications

Rated Frequency (Hz)	50 / 60
Weight (kg)	14.3 (Net)
Rated Operational Voltage (V)	1500 (Main Circuit)
No. of Auxiliary Contacts	2NA + 2NO+ 2NC
Product Type	GF Contractor
Brand	ABB
Auxiliary Circuit Connecting Capacity	Flexible with Ferrule 2 x 0.75-2.5 sq-mm, Flexible with Insulated Ferrule 2 x 0.75-2.5 sq-mm, Flexible 2x0.75-2.5 sq-mm, Solid 2 x 1-4 sq-mm, Stranded 2 x 1-4 sq-mm
Contact Configuration	0NC+2NO
Degree of Protection	IP00, IP20
Depth	300 mm
Height	355 mm
Number of Poles	2
Rated Frequency	50/60 Hz
Rated Impulse Withstand Voltage	8 kV
Rated Voltage	1500 V
Width	253 mm
