Meanwell MDR-20-24 DC POWER SUPPLY 24VDC 1A DIN RAIL MOUNT

Product Code: MDR-20-24

This DC Power Supply has a wide input voltage range of 85 to 264 VAC or 120 to 370VDC. It provides a stable output of 24VDC with a current rating of 1.0A, making it suitable for various applications. With dimensions of 90 x 22.5 x 100mm, it is compact and can be easily mounted on a DIN rail. The LED indication feature allows for easy monitoring of the power supply status.

Technical Specifications

Brand Meanwell
Dimensions (mm) 90H x 100D x 22.5W
Input Voltage AC (V) 85-264
Input Voltage DC (V) 120-370
Mounting Type DIN Rail
Operational Temperature Range (°C) -20 to +70
Output Voltage DC (V) 24
Rated Current (A) 1
Rated Frequency (Hz) 47-63
Rated Power (W) 20
Series MDR-20
