Meanwell HDR-30-24 DC POWER SUPPLY FOR DISPLAYS/GATEWAYS 24VDC, 1.5A, 36W

Product Code: HDR-30-24

This DC Power Supply has a wide input voltage range of 85 to 264 VAC or 120 to 370VDC. It provides a stable output of 24VDC with a current rating of 1.5A, delivering a total power of 36W. The compact dimensions of this power supply are 90mm in height, 35mm in width, and 54.5mm in depth, making it suitable for DIN Rail mounting. It features an LED indicator to show when the power is on and allows for adjustable DC output voltage. Additionally, it offers protection against short circuit, overload, and over voltage situations.

Technical Specifications

Brand Meanwell
Dimensions (mm) 90H x 54.5D x 35W
Input Voltage AC (V) 85-264
Input Voltage DC (V) 120-370
Mounting Type DIN Rail
Operational Temperature Range (°C) -30 to +70
Output Voltage DC (V) 24
Rated Current (A) 1.5
Rated Frequency (Hz) 47-63
Rated Power (W) 36
Series HDR-30
