ABB DDA204A63/0.1 Residual Current Device Block 4-P 230/400VAC 63A 100mA

Product Code: DDA204A63/0.1

  • Supports up to 63 A current
  • Handles voltages of 230/400 VAC
  • Type A residual current protection
  • Complies with IEC/EN 61009 standards
  • Operates efficiently at -25 to 55°C
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 105W x 96H x 76D
No. of Poles 4
Rated Current (A) 63
Rated Frequency (Hz) 50 - 60
Rated Insulation Voltage (V) 500
Rated Impulse Withstand Voltage (kV) 4
Rated Residual Current (mA) 100
Type of Residual Current Type A
Weight (kg) 0.172
Rated Voltage (V) 230/400
Ambient Temperature Range (°C) -25 to 55
Rated Operational Voltage (V) 230
Standards IEC/EN 61009 Ann. G
Product Type Residual Current Device Block
Brand ABB
Ambient Temperature -25 to 55 deg C
Cable Cross Section 25-25 sq-mm Rigid/Flexible
Degree of Protection IP2X
Depth 76 mm
Electrical Durability 10000 Cycles
Height 96 mm
Number of Poles 4
Power Loss 7.6 W
Rated Current 63 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Insulation Voltage 500 V
Rated Voltage 230/400 VAC
Residual Current Type Type A
Standards and Approvals IEC/EN 61009
Weight 0.172 kg
Width 105 mm
