ELKO VS420-40/24V Installation Contactor 4P 20A 24VAC/DC DIN Rail Mount

Product Code: VS420-40/24V

  • Suitable for 24 VAC/VDC systems
  • Handles up to 20 A current
  • Compact size: 35 mm width
  • Reliable IP20 protection rating
  • Meets IEC and EN standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 35W x 62.5H x 57D
Dielectrical Strength (kV) 4
No. of Poles 4
Operational Temperature Range (°C) -5 to 55
Rated Insulation Voltage (V) 415
Rated Supply Voltage AC/DC (V) 24
Weight (kg) 0.17
Rated Operational Current AC-1 (A) 20
No. of Modules - Width 17.5 mm 2
Storage Temperature Range (°C) -30 to 80
No. of Normally-open Contacts 4
Product Type Installation Contactor
Brand ELKO
Series VS
Contact Configuration 4NO
Degree of Protection IP20
Depth 57 mm
Dielectric Strength 4 kV
Height 62.5 mm
Mounting Type DIN Rail
Number of Modules 2
Number of Poles 4
Operational Temperature -5 to 55 deg C
Rated Current 20 A
Rated Insulation Voltage 415 V
Rated Voltage 24 VAC/VDC
Standards and Approvals IEC 60947-4-1, IEC 60947-5-1, IEC 61095, EN 60947-4-1, EN 60947-5-1, EN 61095, EN 60947-1
Storage Temperature -30 to 80 deg C
Weight 0.17 kg
Width 35 mm

Description

The Din Contactor is a compact and versatile device designed for switching resistive loads and three-phase induction motors. It has 4 normally open contacts and a current rating of 20A (AC1). The control voltage can be either 24V AC or DC. With a width of 2 modules (35mm), it can easily be mounted on a DIN Rail. The contactor offers IP20 protection, making it suitable for various applications including heating, lighting, hot water, and storage heating.
