Specifications

Cable Cross Section - Solid/Stranded (mm²)	Top/Bottom - 25/25
Cable Cross Section - Flexible (mm²)	Top/Bottom - 16/16
Dimensions (mm)	17.5W x 85H x 69D
No. of Poles	1
Pole Width (mm)	17.5
Power Loss (W)	2.53/Pole
Rated Conditional Short-Circuit Current - Inc (kA)	10
Pollution Degree	3
Rated Current (A)	40
Rated Frequency (Hz)	50/60
Rated Insulation Voltage (V)	440
Rated Impulse Withstand Voltage (kV)	4
Rated Operational Voltage DC (V)	60
Rated Operational Voltage AC (V)	240
Maximum Operational Voltage DC (V)	63
Maximum Operational Voltage AC (V)	252
Minimum Operational Voltage AC (V)	12
Voltage Type	AC/DC
Rated Voltage (V)	240
Poles	1P
Current Rating (A)	40
Family	SHD200
AC Voltage (V)	240/415
DC Voltage (V)	60
Inc-Rated Conditional Short Circuit Capacity (kA)	10
Impulse Withstand Voltage (kV/1.2µS)	4
No. of Normally-open Contacts	1
Built-in Depth (mm)	69
Width in Number of Modular Spacings	1
Product Type	Switch Disconnector
Brand	ABB
Series	SHD200
Application	Domestic
Bulbar Cross Section	>=16 sq-mm
Cable Cross Section	25 sq-mm Top, 25 sq-mm Bottom
Colour	RAL 7035 Light Grey
Degree of Protection	IP20
Depth	69 mm
Height	85 mm
Housing Material	Insulation Group II, RAL 7035
Mounting Type	DIN Rail
Number of Poles	1
Pole Width	17.5 mm
Power Loss	2.53 W
Rated Current	40 A
Rated Frequency	50/60 Hz
Rated Impulse Withstand Voltage	4 kV
Rated Insulation Voltage	440 V
Rated Voltage	230/400 VAC
Short Circuit Capacity	10 kA
Standards and Approvals	AS/NZS 60947-3
Switching Type	Off Switch
Width	17.5 mm

Description

SHD201/40 - Switch Disconnector 1P, 40A
