This pushbutton is designed for industrial and commercial environments, offering robust performance with its comprehensive features. Rated for both 230 VAC and DC, it provides flexibility in various applications. The illumination feature enhances visibility, crucial in settings where quick identification is necessary.
With an IP66 protection rating on the front, this pushbutton ensures resilience against dust and powerful water jets, making it suitable for harsh conditions. Meanwhile, the IP20 terminal rating indicates basic protection against finger contact. This dual-level protection makes it ideal for demanding environments such as mining, construction, and heavy industry.
Compliance with multiple standards like EN IEC 60947-1 and UL 508 underscores its reliability and safety across global markets. The ambient temperature range of -25 to 70 degrees Celsius allows operation in diverse climates without compromising functionality.
The device boasts a rated insulation voltage of 690 V and a rated impulse withstand voltage of 6 kV, ensuring durability under electrical stress. Its contact configuration includes one normally open (NO) and one normally closed (NC) contact—versatile enough to suit different control circuit needs.
Featuring a flush actuator type with a clear built-in LED lamp, this pushbutton offers straightforward operation while maintaining aesthetic simplicity. The LED block light type ensures energy-efficient illumination that’s easy to maintain over time.
The button's color scheme—green on the upper part and red on the lower—is intuitive for operators who rely on color-coded systems for quick decision-making processes. Although there's no legend text included, the clear design conveys its function effectively within control panels or machinery interfaces.
Constructed with a plastic bezel material around a standard cutout size of 22 mm, installation is streamlined into existing setups or new projects alike. The rated thermal current stands at 10 A—suitable for handling typical industrial loads without overheating concerns.
Included components such as the operator unit, contact block holder, and LED block simplify integration into systems by providing everything needed out-of-the-box. This comprehensive package reduces additional procurement steps during setup phases.
Overall, this pushbutton meets high standards required by professionals working in challenging sectors like mining or construction where reliability cannot be compromised due to environmental factors or operational demands.
