Product Code: MPDIFCGR111

Illuminated pushbutton with clear LED lamp
IP66 front protection for harsh environments
Operates at 24 VAC/DC, suitable for mining
Dual colour button: green upper, red lower
Flush actuator with plastic bezel

Specifications

Contacts	1NO + 1NC
Rated Frequency (Hz)	50/60
Rated Voltage AC/DC (V)	24
LED Block Rated Voltage	24VAC/DC
Upper/Lower Button Text	No Text/No Text
Bezel Material	Plastic
Product Type	Double Pushbutton Kit
Brand	ABB
Actuator Type	Flush/Flush
Ambient Temperature	-25 to 70 deg C
Application	For mining, construction and heavy industry applications
Bezel Material	Plastic
Button Colour	Green (Upper), Red (Lower)
Colour	Clear
Contact Configuration	1NO+1NC
Cutout Size	22 mm
Degree of Protection	IP66 Front, IP20 Terminal
Illumination	Illuminated
Includes	Operator, Contact Block, Contact Block Holder and LED Block
Lamp Colour	Clear
Lamp Type	Built-in LED
LED Colour	Clear
Legend	No Text
Light Blocks Type	LED Block
Rated Impulse Withstand Voltage	6 kV
Rated Insulation Voltage	690 V
Rated Thermal Current	10 A
Rated Voltage	24 VAC/DC
Standards and Approvals	EN IEC 60947-1, EN IEC 60947-5-1, EN IEC 60947-5-5, EN IEC 60073, EN IEC 60529, EN 50013, DIN 40050-9, UL 508, CSA C22.2 No. 14

Description

The Illuminated Double Pushbutton Clear Indicator is a 24VAC/DC device that features an upper-green and lower-red flush/flush design. It has 1 normally open (NO) and 1 normally closed (NC) contact. This product does not include any texts. The kit includes an operator, contact block, and contact block holder. It is part of the Modular Plastic Range.
