When selecting a pushbutton for industrial applications, it's essential to consider its technical specifications and suitability for the intended environment. This particular pushbutton is designed with practicality and durability in mind, making it an ideal choice for mining, construction, and heavy industry sectors.
Operating at a rated voltage of 220 VDC, this illuminated pushbutton ensures clear visibility even in dimly lit environments thanks to its built-in LED lamp. The lamp emits a yellow light, providing an immediate visual cue when the button is engaged. The actuator's flush design enhances safety by reducing accidental activation risks.
The device boasts robust protection levels with an IP66 rating on the front side, safeguarding against dust ingress and powerful water jets. Meanwhile, the terminal area is protected up to IP20 standards. It's crafted to endure harsh conditions within ambient temperatures ranging from -25°C to 70°C.
For electrical reliability, this pushbutton meets several international standards including EN IEC 60947-1 and UL 508 among others. It features a contact configuration of 1NO+1NC (one normally open and one normally closed), offering flexibility in circuit design. With a rated insulation voltage of 690 V and an impulse withstand voltage of 6 kV, it promises dependable performance under demanding electrical conditions.
The momentary function allows for temporary operation while maintaining simplicity in use; once released, it returns to its original position automatically. The button itself is color-coded with green on the upper part and red on the lower part—an intuitive design that helps users quickly identify operational states or functions.
Constructed with a plastic bezel material for added resilience without compromising weight considerations, it fits neatly into standard cutout sizes of 22 mm diameter—a common dimension that simplifies integration into existing panels or systems.
Included components such as the operator unit, contact block holder along with LED block ensure straightforward installation and maintenance processes are achievable without additional purchases or modifications required post-purchase.
In summary, this pushbutton stands out as a reliable component tailored specifically towards rigorous industrial settings where both functionality and compliance with stringent safety standards are paramount priorities.
