When it comes to selecting a reliable pushbutton for industrial applications, this product stands out with its robust features and compliance with international standards. Designed for demanding environments such as mining, construction, and heavy industry, it ensures both functionality and durability.
The pushbutton operates at a rated voltage of 230 VAC/DC and is illuminated by a built-in LED light block. The yellow lamp enhances visibility in various lighting conditions, contributing to operational safety. Its momentary function means the button returns to its original position after being pressed, providing precise control over machinery or processes.
With an IP66 rating on the front side and IP20 at the terminal, this pushbutton offers excellent protection against dust and water ingress while maintaining electrical integrity. It meets several standards including EN IEC 60947-1, EN IEC 60947-5-1, EN IEC 60947-5-5 among others—ensuring compliance with global safety requirements.
The ambient temperature range of -25 to 70 degrees Celsius allows it to perform reliably in extreme conditions. Its rated insulation voltage of 690 V and an impressive impulse withstand voltage of 6 kV highlight its capability in handling high-stress electrical environments.
Featuring a contact configuration of 1NO+1NC (one normally open and one normally closed contact), this pushbutton provides versatility for different circuit designs. A thermal current rating of 10 A further supports its use in heavy-duty applications.
Aesthetically designed with a flush actuator type, the button combines white on the upper part with black on the lower part for clear distinction during operation. The bezel material is crafted from durable plastic ensuring longevity without compromising on weight or ease of installation.
The cutout size required is standard at 22 mm making it compatible with most panel installations. Included components such as the operator, contact block holder, and LED block simplify assembly processes saving time during setup or maintenance routines.
In summary, this product’s combination of technical specifications makes it well-suited for challenging industrial settings where reliability cannot be compromised.
