ABB CE3K1-10R-11 Non-Illuminated Machine Stop 30mm 1NO+1NC

Product Code: CE3K1-10R-11

  • Amber pushbutton for clear visibility
  • Durable polycarbonate construction
  • Operates in -25 to 50°C range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO+1NC
Dimensions (mm) 30W x 30H x 103D
Maximum Operational Voltage DC (V) 300
Maximum Operational Voltage AC (V) 300
Mushroom Diameter (mm) 30
Operational Temperature Range (°C) -25 to +70
Rated Frequency (Hz) 50/60
Rated Operational Current 240V AC (A) 1
Rated Operational Current 125V DC (A) 0.2
Rated Operational Current 24V DC (A) 0.3
Product Type Non-Illuminated Machine Stop
Brand ABB
Colour Amber
Degree of Protection IP66 (Front), IP20 (Terminals)
Illumination Non-Illuminated
Material Polycarbonate
Mode of Operation Maintained
Operational Temperature -25 to 50 deg C
Release Method Key release, roins 455, Key code 71

Description

This Non-Illuminated Emergency Stop Pushbutton is designed for use in emergency situations. It features a red colour and has a 30mm diameter. The pushbutton has a 1NO/1NC configuration, meaning it has one normally open contact and one normally closed contact. It also has a key release mechanism with roins 455 Key code 71. This product is part of the Compact range.
