ELKO VS425-04/24V Installation Contactor 4P 25A 24VAC/DC DIN Rail Mount

Product Code: VS425-04/24V

1

Specifications

Product Type	Installation Contactor
Brand	ELKO
Series	VS
Contact Configuration	4NC
Degree of Protection	IP20
Depth	60 mm
Dielectric Strength	4 kV
Height	85 mm
Mounting Type	DIN Rail
Number of Modules	2
Number of Poles	4
Operational Temperature	-5 to 55 deg C
Rated Current	25 A
Rated Insulation Voltage	440 V
Rated Voltage	24 VAC/VDC
Standards and Approvals	IEC 60947-4-1, IEC 60947-5-1, IEC 61095, EN 60947-4-1, EN 60947-5-1, EN 61095, EN 60947-1
Storage Temperature	-30 to 80 deg C
Weight	0.213 kg
Width	35 mm

Documents

IPD Product Catalogue V17

ELKO Datasheet
