Product Code: EP-2634

Optimize your automation systems with the Emerson RSTi-EP Digital Output Module. This compact, DIN rail-mounted PLC from the RSTi-EP series is designed for distributed applications and offers a high channel density of 4 to 16 points. It supports both positive and negative logic and can handle output ratings from 0.5 to 6A at 24VDC across 1,2,3, or 4 wire configurations. With dual RJ45 ports, it ensures network redundancy and seamless integration with PROFINET RT, PROFIBUS, Modbus TCP, and EtherCAT networks. Ideal for machine control, light process control, and general automation tasks, this module is a versatile choice for modern industrial environments.

Maximum Temperature (°C)	60
Minimum Temperature (°C)	-20
Brand	Emerson
Series	RSTi-EP
Mounting Type	DIN Rail
Communication Protocols	MODBUS, PROFINET, PROFIBUS, EtherCAT, EtherNet/IP
Current Consumption	8mA; 20mA + Loads, 20.4-28.8V DC
Maximum Nominal Output Voltage DC (V)	24
No. of Digital Outputs	4
No. of Ethernet Ports	2
No. of IO	4
No. of Output Points	4
Nominal Output Current (A)	2
Rated Maximum Operational Voltage DC (V)	28.8
Rated Minimum Operational Voltage DC (V)	20.4
Redundancy	PNSR
Degree of Protection	IP20
Standards and Approvals	ATEX/IECeX

Programmable Logic Controllers & I/O

EMERSON RSTI-EP 4CH DIG OUT POS/NEG LOGIC, 24VDC 4 WIRE RSTI-EP 4PT DIGITAL OUT 2AMP EP-2634

Product Code: EP-2634

Technical Specifications
