When selecting a conductor holder for industrial and commercial applications, understanding the technical specifications is crucial. This particular model offers robust performance with a rated current capacity of 19,500 A and 13,800 A, ensuring it can handle substantial electrical loads. The connection type features a 20 mm fixed ball point, providing secure and reliable connectivity essential for maintaining system integrity.
Mounting this conductor holder is straightforward thanks to its thread bolt design. It adheres to rigorous standards such as EN/IEC 61230 (DIN VDE 0683-100) and DIN 43673-1, assuring compliance with international safety and performance regulations.
Weighing in at just 259 grams, this conductor holder strikes an excellent balance between durability and manageability. Its compatibility with earthing rods makes it versatile for various grounding applications.
Constructed from electrolytic copper with a tin coating, the material choice enhances conductivity while offering corrosion resistance—a critical factor in extending the lifespan of electrical components exposed to harsh environments. The tightening torque range of 50-65 N-m ensures that connections are both secure and maintainable over time without risk of damage or loosening.
With a cross-sectional area of 70 sq-mm, this product supports efficient current distribution across its structure. The angle design set at 90 degrees facilitates optimal alignment within your setup for ease of installation.
The thread size is M12 x 35 mm which provides compatibility with standard fittings used across many installations in the industry. These specifications cater well to professionals seeking reliability and efficiency in their electrical systems.
This conductor holder's thoughtful engineering ensures it meets demanding operational requirements while maintaining ease of use—a valuable asset for any technical project requiring dependable earthing solutions.
