Specifications

Dimensions (mm)	45W x 82H x 56D
Suitable For	Earthing
Weight (kg)	0.41
Type	Short-Circuiting Devices
Wire Cross Section (mm²)	95
Weight (g)	410
Maximum Output Short-circuit Current (A)	26.5k (0.5s)
Mounting Method	For circular conductor
Outer Diameter (mm)	25
Reference No.	725010
Product Type	Fixed Ball Point
Brand	DEHN
Connection Type	25 mm Fixed Ball Point
Cross Section	95 sq-mm
Depth	56 mm
Height	82 mm
Material	Electrolytic Copper, Tin Coated Copper
Rated Current	26500 A, 18700 A
Standards and Approvals	EN/IEC 61230 (DIN VDE 0683-100)
Suitable For Use With	10 mm Round Conductor
Weight	410 g
Width	45 mm
