IDECYW4B-M1E03B Non-Illuminated Pushbutton 22mm Flush Momentary Black 3NC

Product Code: YW4B-M1E03B

  • Non-illuminated flush actuator pushbutton
  • IP65 front protection, IP20 terminal
  • 5 million ops single contact block
  • cULus, CE, UKCA, CCC certified
  • Operates in -20 to 55°C range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-closed Contacts 3
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Flush
Bezel Material Metal
Button Colour Black
Colour Black
Contact Configuration 3NC
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Flush - Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW4B-M1E03B is a flush pushbutton featuring a black metal bezel and designed for 22mm mounting. This compact and lightweight unit includes three normally closed (NC) contact blocks that are only 10mm thick, optimizing space within control panels. The pushbutton's removable operator and separate contact block design facilitate straightforward installation and maintenance. Additionally, it offers the versatility of unibody pilot lights and key selector switches to suit various industrial applications.
