When it comes to safeguarding your high-voltage systems, reliability and precision are paramount. Designed for industrial and commercial applications, this HV Fuse Link offers robust protection with a rated current of 1 A. Operating efficiently at a rated voltage of 24 kV, this fuse link is an ideal choice for ensuring the safety of electrical equipment in demanding environments.
Weighing in at 5.071 lb, this fuse link combines durability with manageability. Its dimensions—56 mm in diameter and 442 mm in length—make it suitable for various setups while maintaining a compact profile that facilitates easy integration into existing systems.
The fuse's mounting type is clip-based, allowing for straightforward installation and replacement without the need for extensive downtime or specialized tools. This feature ensures that maintenance can be performed swiftly, minimizing disruptions to operations.
With an impressive breaking capacity of 63 kA, this HV Fuse Link is designed to handle significant fault currents effectively, providing peace of mind by preventing potential damage during electrical faults. The striker indicator with an 80N force provides clear visual confirmation when the fuse has operated, enhancing safety protocols by enabling quick identification and response from maintenance teams.
Power dissipation stands at just 2.2 W, highlighting the product’s efficiency in managing energy loss during operation—a critical factor in reducing overall system heat generation and improving longevity.
Constructed from ceramic material both for its body and insulation components, this fuse link delivers excellent thermal stability and resistance to environmental stresses such as moisture or chemical exposure. The use of silver-plated copper for connections ensures optimal conductivity while offering corrosion resistance—a vital consideration for installations exposed to varying atmospheric conditions.
The terminal type is cylindrical, which supports secure connections essential for maintaining consistent performance over time. This design choice underscores the product’s emphasis on reliability by minimizing potential points of failure due to poor connectivity or wear over extended periods.
In summary, this HV Fuse Link represents a dependable solution tailored to meet rigorous industry standards where safety cannot be compromised. Its technical specifications align well with those seeking a comprehensive protective device capable of integrating seamlessly into high-voltage networks while delivering consistent performance under pressure.
