Industrial Fuse Links

IPD FUSE LINK 16A 415VAC 80kA F1 CLIP-IN BS88 TYPE NS16

Product Code: NS16

The NS Clip-in (F1) BS fuse links are engineered to safeguard general purpose applications. They fall under the gG/gM utilization categories and have a tested breaking capacity of up to 80 kA. These fuse links have a rated current of 16A and can handle voltages of 415VAC/240VDC.

Technical Specifications

Brand IPD
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Connection Type Clip-In
Diameter (mm) 13.5
Fuse Construction Type F1
Pack Quantity 10
Rated Current (A) 16
Rated Voltage AC (V) 415
Rated Voltage DC (V) 240
Standards and Approvals IEC 60269, BS88 Part 6
Suitable Fuse Holder SC20/S32
Total Length (mm) 59
Utilisation Category gG
