Mersen AJT175 Power Fuse 175A 600/500VAC/DC Class J 41.3mm Dia x 146mm L Blade Terminal Class J 200kA

Product Code: AJT175

  • Rated for 175 A current
  • Voltage capacity: 600/500 VAC/VDC
  • High breaking capacity of 200 kA
  • Mounts via clip or bolt
  • Blade terminal type
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Rated Current (A) 175
Rated Voltage DC (V) 500
Rated Voltage AC (V) 600
Body Size (mm) 41 x 76
Functionality Time Delay
Interrupting Rating AC (kA) 200
Interrupting Rating DC (kA) 100
Product Type Time Delay Power Fuse
Brand MERSEN
Body Material GMG
Body Size 41.3 mm Dia x 146 mm L
Body Style Bolted Tag
Breaking Capacity 200 kA
Connection/Terminal Material Brass
Fuse Class Class J
Insulation Material GMG
Mounting Type Clip, Bolted
Rated Current 175 A
Rated Frequency 50/60 Hz
Rated Voltage 600/500 VAC/VDC
Terminal Type Blade
Weight 0.3465 kg

Description

AJT Time delay Class 'J' ferrule type fuses are designed to handle typical motor and transformer inrush currents. They have time-delay characteristics and provide superior current-limiting ability. These fuses have a voltage rating of 600VAC/500VDC and a rated current of 175A.
