Mersen OTM5 Fast-Acting Midget Fuse 5A 250VAC 0.41 in Dia 1.5 in L 10kA Interrupt Ferrule

Product Code: OTM5

  • Rated for 5A and 250VAC use
  • Compact size: 1.5 in length
  • Clip mounting for easy installation
  • Handles up to 10kA interrupt rating
  • Tin plated copper terminals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Body Size (mm) 10 x 38
Functionality Fast Acting
Rated Current (A) 5
Rated Voltage AC (V) 250
Interrupting Rating AC (kA) 10
Product Type Fast-Acting Midget Fuse
Brand MERSEN
Body Material Paper
Body Style Ferrule
Connection/Terminal Material Tin Plated Copper
Diameter 0.41 in
Insulation Material Paper
Interrupt Rating 10 kA
Length 1.5 in
Mounting Type Clip
Rated Current 5 A
Rated Frequency 50/60 Hz
Rated Voltage 250 VAC
Terminal Type Ferrule
Weight 0.012 lb

Description

OTM midget fast-acting ferrule type fuses are an affordable solution for protecting general purpose lighting, heating, and control circuits. These fuses have a voltage rating of 250VAC and a rated current of 5A. They can interrupt short circuit currents up to 10kA. Additionally, they are UL Listed to standard 248-14.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
