Product Code: OT500

Rated for 500 A, suitable for high current applications
Operates at 250 VAC/VDC with 50/60 Hz frequency
High breaking capacity of 50 kA
Durable poly tube body with blade terminals
Tin plated copper connections ensure reliability

Specifications

Body Size (mm)	66 x 150
Functionality	General Purpose
Rated Current (A)	500
Rated Voltage AC/DC (V)	250
Interrupting Rating AC (kA)	50
Interrupting Rating DC (kA)	20
Product Type	Fast-Acting General Purpose Fuse
Brand	MERSEN
Body Material	Poly Tube
Body Size	2.56 in Dia x 10.38 in L
Body Style	Blade
Breaking Capacity	50 kA
Connection/Terminal Material	Tin Plated Copper
Fuse Class	Class K5
Insulation Material	PolyTube
Mounting Type	Clip
Rated Current	500 A
Rated Frequency	50/60 Hz
Rated Voltage	250 VAC/VDC
Terminal Type	Blade
Weight	2.158 lb

Description

The One-Time OT general purpose fuses offer affordable protection for feeder and branch-circuits that supply lighting, heating, and other non-motor loads. These fuses have a voltage rating of 250V AC/DC and a rated current of 500A. They are capable of safely interrupting short circuit currents up to 50kA/AC and 20kA/DC in all ratings.

Documents

IPD Product Catalogue

IPD Product Catalogue V17

Mersen OT500 Fast-Acting General Purpose Fuse 500A 250VAC/DC Class K5 2.56 in Dia x 10.38 in L Blade Terminal
