Industrial Fuse Links

IPD FUSE LINK 32A 415VAC 80kA F1 CLIP-IN BS88 TYPE NS32

Product Code: NS32

The NS Clip-in (F1) BS fuse links are designed for general purpose applications. They have a breaking capacity of up to 80 kA and are rated for a current of 32A and voltages of 415VAC/240VDC. These fuse links are suitable for gG/gM utilization categories.

Technical Specifications

Pack Quantity 10
Brand IPD
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Connection Type Clip-In
Fuse Construction Type F1
Rated Current (A) 32
Rated Voltage AC (V) 415
Rated Voltage DC (V) 240
Suitable Fuse Holder SC32
Diameter (mm) 13.5
Total Length (mm) 59
Utilisation Category gG
Standards and Approvals IEC 60269, BS88 Part 6
