MERSEN A4J200 FUSE LINK 200A 600VAC 300VDC CLASS J FAST ACTING 41X76mm BOLT-IN

Product Code: A4J200

The A4J Fast-acting Class 'J' ferrule type fuses provide excellent current-limiting protection for various applications such as capacitors, load centers, panelboards, switchboards, busducts, feeder circuits, circuit breakers, lighting, heating, and general loads. These fuses have a voltage rating of 600VAC/300VDC and a rated current of 200A.

Technical Specifications

Brand MERSEN
Body Style Bolted Tag
Fuse Class Class J
Interrupting Rating AC (kA) 200
Interrupting Rating DC (kA) 100
Body Size (mm) 41 x 76
Functionality Fast Acting
Rated Current (A) 200
Rated Voltage AC (V) 600
Rated Voltage DC (V) 300
