Mersen A4J90 Power Fuse 90A 600/300VAC/DC Class J 1.06 in Dia x 4.63 in L 200kA Fast Acting

Product Code: A4J90

  • Rated for 90 A, 600/300 VAC/VDC
  • High breaking capacity of 200 kA
  • Compact size: 1.06 in Dia x 4.63 in L
  • Easy clip mounting system
  • Durable GMG body and insulation
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Rated Current (A) 90
Rated Voltage DC (V) 300
Rated Voltage AC (V) 600
Body Size (mm) 29 x 67
Functionality Fast Acting
Interrupting Rating AC (kA) 200
Interrupting Rating DC (kA) 100
Product Type Power Fuse
Brand MERSEN
Body Material GMG
Body Size 1.06 in Dia x 4.63 in L
Body Style Bolted Tag
Breaking Capacity 200 kA
Connection/Terminal Material Silver Plated Copper
Fuse Class Class J
Insulation Material GMG
Mounting Type Clip
Rated Current 90 A
Rated Frequency 50/60 Hz
Rated Voltage 600/300 VAC/VDC
Terminal Type Blade
Weight 0.24 lb

Description

The A4J Fast-acting Class 'J' ferrule type fuses provide exceptional current-limiting protection for various applications, including capacitors, load centers, panelboards, switchboards, busducts, feeder circuits, circuit breakers, lighting, heating, and general loads. These fuses have a voltage rating of 600VAC/300VDC and a rated current of 90A.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
