Mersen OTS50 Fast-Acting General Purpose Fuse 50A 600/300VAC/DC Class K5 1.06 in Dia x 5.5 in L Ferrule Terminal

Product Code: OTS50

  • UL North American standard fuse
  • 50 A current, 600/300 VAC/VDC rating
  • High breaking capacity of 50 kA
  • Clip mounting for easy installation
  • Durable poly tube body with copper terminals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Rated Current (A) 50
Rated Voltage DC (V) 300
Rated Voltage AC (V) 600
Body Size (mm) 27 x 139
Functionality General Purpose
Interrupting Rating AC (kA) 50
Interrupting Rating DC (kA) 20
Product Type Fast-Acting General Purpose Fuse
Brand MERSEN
Body Material Poly Tube
Body Size 1.06 in Dia x 5.5 in L
Body Style Ferrule Long
Breaking Capacity 50 kA
Connection/Terminal Material Copper
Fuse Class Class K5
Insulation Material PolyTube
Mounting Type Clip
Rated Current 50 A
Rated Frequency 50/60 Hz
Rated Voltage 600/300 VAC/VDC
Terminal Type Ferrule
Weight 0.215 lb

Description

The One-Time OTS general purpose fuses offer affordable protection for feeder and branch-circuits that supply power to lighting, heating, and other non-motor loads. These fuses have a voltage rating of 600VAC/300VDC and a rated current of 50A. They are UL listed to standard 248-14.
