IDEC LF1B-NF4P2SHY21M Illumination Unit White IP65 1080mm D 1m L Cable 24V

Product Code: LF1B-NF4P2SHY21M

  • Energy-efficient 11.6W LED lighting
  • Robust IP65 protection for harsh environments
  • Operates in -30 to 55°C temperature range
  • Compliant with CE, cULus, UL, CSA standards
  • Bright yellow illumination with white cover
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Illumination Unit
Brand IDEC
Series LF1B-N
Cable Length 1 m
Cover Colour White
Degree of Protection IP65
Depth 1080 mm
Humidity 45-85%
Illumination Colour Yellow
Operational Temperature -30 to 55 deg C
Rated Current 830 mA
Rated Power 11.6 W
Rated Voltage 24 V
Standards and Approvals CE, cULus, UL2108, UL8750, CSA C22.2 No. 250.0 EN55015, FCC Part 15/Class B, EN61547
Weight 740 g

Description

<p>The LF1B-N series LED Illumination Unit is a robust lighting solution designed for industrial and commercial applications. With its reliable performance, this unit operates at a rated voltage of 24 V and delivers an efficient power output of 11.6 W. The yellow illumination color provides clear visibility, making it suitable for various settings where specific lighting conditions are required.</p><p>Built to withstand challenging environments, the LF1B-N series offers an IP65 degree of protection, ensuring resistance against dust ingress and water jets from any direction. This makes it ideal for both indoor and outdoor installations, particularly in areas exposed to moisture or particulate matter.</p><p>The unit&amp;#39;s operational temperature range spans from -30 to 55 degrees Celsius, allowing it to perform consistently across diverse climates without compromising on reliability. Coupled with a humidity tolerance between 45% and 85%, this LED illumination unit is well-suited for use in different atmospheric conditions.</p><p>Weighing just 740 grams and featuring a depth of 1080 mm, the LF1B-N series is easy to handle during installation while providing ample coverage with its extended length. The white cover complements most industrial aesthetics while protecting the internal components.</p><p>Connectivity is straightforward with a cable length of one meter, offering flexibility in placement without needing additional extensions in many scenarios. The unit draws a rated current of 830 mA, maintaining energy efficiency alongside its robust performance metrics.</p><p>Adhering to stringent safety standards and approvals including CE certification as well as cULus listings under UL2108 and UL8750 standards, this product meets high-quality benchmarks recognized internationally. Additionally certified by CSA C22.2 No. 250.0 EN55015 FCC Part 15/Class B EN61547 these certifications affirm its compliance with electromagnetic compatibility requirements ensuring minimal interference with other electronic devices.</p><p>In summary the LF1B-N series LED Illumination Unit represents an optimal balance between durability performance efficiency and regulatory compliance making it an excellent choice for professionals seeking dependable lighting solutions capable of enduring demanding operational environments.</p>
