IDEC YW1L-M2E11Q4G ILLUMINATED PUSHBUTTON GREEN LED EXTENDED MOMENTARY 1NO/C 24VAC/DC

Product Code: YW1L-M2E11Q4G

The IDEC YW1L-M2E11Q4G is an illuminated pushbutton equipped with a green LED and designed for extended momentary action. It features a contact configuration of 1 Normally Open (NO) and 1 Normally Closed (NC). This pushbutton is suitable for use with a 24VAC/DC power supply and fits a 22mm mounting size. For enhanced safety, it includes IP20 finger-safe terminals.

Technical Specifications

Brand IDEC
Bezel Type Plastic
Contact Material Silver
Contacts 1NO+1NC
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Degree of Protection IP65 (Front), IP20 (Terminals)
Illumination Illuminated
Insulation Resistance (MO) 100
Lamp Included
Lamp Type Included
LED Colour Green
Mode of Operation Momentary
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Voltage AC/DC (V) 24
Series YW
Terminal Type Screw (M3.5)
