IDEC YW1L-M2E11Q4R ILLUMINATED PUSHBUTTON RED LED EXTENDED MOMENTARY 1NO/C 24VAC/DC

Product Code: YW1L-M2E11Q4R

The IDEC YW1L-M2E11Q4R is an illuminated pushbutton equipped with a red LED for clear visibility. It offers extended momentary action and includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration. Designed for 24VAC/DC operation, this pushbutton fits a standard 22mm panel hole and ensures user safety with its IP20 rating.

Technical Specifications

Brand IDEC
Bezel Type Plastic
Contact Material Silver
Contacts 1NO+1NC
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Degree of Protection IP65 (Front), IP20 (Terminals)
Illumination Illuminated
Insulation Resistance (MO) 100
Lamp Included
Lamp Type Included
LED Colour Red
Mode of Operation Momentary
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Voltage AC/DC (V) 24
Series YW
Terminal Type Screw (M3.5)
