IDECYW1L-MF2E11Q4PW Illuminated Pushbutton 22mm Extended w/Full Shroud Momentary Pure White 24VAC/DC 1NO+1NC

Product Code: YW1L-MF2E11Q4PW

  • Illuminated pushbutton with pure white LED
  • IP65 front protection for robust use
  • Extended actuator with full shroud
  • Mechanical life up to 5 million operations
  • Operates in -20 to 55°C environments
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO+1NC
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Voltage AC/DC (V) 24
Mounting Hole Diameter (mm) 22
Lamp Included
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended with Full Shroud
Bezel Material Plastic
Bezel Type Plastic
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Pure White
Lamp Type Built-in LED
LED Colour White
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 24 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-MF2E11Q4PW is an illuminated pushbutton featuring a Pure White LED with an extended shroud for clear visibility. It offers momentary action and includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration. Designed for 24VAC/DC power systems, this pushbutton ensures easy installation with its 22mm mounting size. It carries an IP20 rating, signifying protection against solid objects without the need for additional finger safe terminals.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
