IDECHW1L-M1F11S-K Illuminated Pushbutton Kit 22mm Flush Momentary Blue 1NO+1NC

Product Code: HW1L-M1F11S-K

  • Illuminated pushbutton with flush actuator
  • IP65 front protection, IP20 terminal rating
  • Durable design: 5 million operations lifespan
  • UL, CE, ULKA, CSA certified for safety
  • Operates in -25 to 60°C temperature range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO+1NC
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -25 to +50
Rated Continuous Current (A) Contact Rating - 10
Pollution Degree 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Impulse Withstand Voltage (kV) 2.5
Mounting Hole Diameter (mm) 22
Tightening Torque (Nm) Locking Ring - 2.0
Lamp Not Included
Product Type Pushbutton Kit
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Blue
Lamp Type Without Lamp
LED Colour Blue
Mechanical Life 5 million Operations
Mode of Operation Momentary
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-M1F11S-K is an illuminated pushbutton designed for clear and secure operation. This blue, round pushbutton features a flush design and supports full voltage applications. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration, ensuring versatile use in various control circuits. Additionally, it is built with tamperproof features to enhance security measures in critical environments.
