IDECHW1L-M1F11HG-K Illuminated Pushbutton Kit 22mm Flush Momentary Green 110/6VAC/DC 1NO+1NC

Product Code: HW1L-M1F11HG-K

  • Illuminated pushbutton with flush actuator
  • Durable with 5 million operations lifespan
  • IP65 front protection against dust and water
  • Green lamp colour, momentary function
  • UL, CE, CSA certified for safety standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Components Contact Block Adaptor Lead Holder 1 NO Contact Block 1 NC Contact Block Transformer Round Momentary Operator Safety Lever Lock
No. of Normally-open Contacts 1
No. of Normally-closed Contacts 1
Product Type Pushbutton Kit
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type Without Lamp
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Rated Voltage 110/6 VAC/DC
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-M1F11HG-K is a momentary illuminated pushbutton with a flush green operator and a plastic bezel. It operates with a transformer at 110/6V and includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration, without the lamp. This pushbutton is designed for quick and easy actuation in various industrial applications.
