IDECHW1L-M1F11M4R-K Illuminated Pushbutton Kit Transformer 22mm Flush Momentary Red 240/6VAC/DC 1NO+1NC

Product Code: HW1L-M1F11M4R-K

  • Illuminated pushbutton with flush actuator
  • IP65 front protection for harsh environments
  • 1NO+1NC contact configuration, silver contacts
  • Mechanical life of 5 million operations
  • UL listed, CE marked, CSA certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO+1NC
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -25 to +50
Rated Continuous Current (A) Contact Rating - 10
Pollution Degree 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Rated Impulse Withstand Voltage (kV) 2.5
Mounting Hole Diameter (mm) 22
Tightening Torque (Nm) Locking Ring - 2.0
Lamp Not Included
Product Type Pushbutton Kit
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Illumination Circuit Transformer
Insulation Resistance 100 MOhm
Lamp Colour Red
Lamp Type Without Lamp
LED Colour Red
Mechanical Life 5 million Operations
Mode of Operation Momentary
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Rated Voltage 240/6 VAC/DC
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-M1F11M4R-K is an illuminated pushbutton featuring a red flush button for clear visibility. It operates with a momentary action and includes a transformer suitable for 240/6V applications. This pushbutton comes with one normally open (NO) and one normally closed (NC) contact, ensuring versatile use in various control circuits. Its tamperproof design enhances security, making it ideal for critical industrial environments.
