IDECHW4L-M1F11-M4-A Illuminated Pushbutton Transformer 22mm Flush Momentary Amber 240/6VAC/DC 1NO+1NC

Product Code: HW4L-M1F11-M4-A

  • Illuminated, amber LED pushbutton
  • IP65 front protection for durability
  • 5 million operations mechanical life
  • Flush actuator with 22 mm diameter
  • UL, CE, CSA certified for safety
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 1
No. of Normally-closed Contacts 1
Terminal Shape Screw Terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Material Metal
Bezel Shape Round
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Illumination Circuit Transformer
Illumination Colour Amber
Insulation Resistance 100 MOhm
Lamp Colour Amber
Lamp Type LED
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Frequency 50/60 Hz
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Rated Voltage 240/6 VAC/DC
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW4L-M1F11-M4-A is an illuminated pushbutton featuring a flush operator and momentary action for quick and responsive control. It comes with a transformer that supports 240/6V, ensuring compatibility with various electrical systems. This pushbutton includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact, along with a lamp for clear indication. Its durable metal bezel provides robustness suitable for industrial environments.
