IDECYW1L-M2E10QM3R Illuminated Pushbutton 22mm Extended Momentary Red 230/240VAC/DC 1NO

Product Code: YW1L-M2E10QM3R

  • Illuminated pushbutton with built-in red LED
  • IP65 front protection, ideal for harsh environments
  • High mechanical life up to 5 million operations
  • Rated voltage: 230/240 VAC/DC, 10 A continuous current
  • Compliant with cULus, CE, UKCA, and CCC standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 230/240
Operating Voltage AC (V) 230/240
No. of Normally-open Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended
Bezel Material Plastic
Colour Red
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Red
Lamp Type Built-in LED
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Momentary Extended
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 230/240 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-M2E10QM3R is a compact, illuminated pushbutton designed for efficient use of space with its 10mm thick contact blocks. This momentary pushbutton features an extended red LED for clear visibility and operates at 240V within a 22mm size. Its lightweight design includes a plastic bezel and a removable operator for straightforward maintenance. The separate contact block simplifies installation and removal, enhancing user convenience in various applications.
