IDECYW1L-M2E11Q0G Illuminated Pushbutton 22mm Extended Momentary Green 250VAC/DC 1NO+1NC

Product Code: YW1L-M2E11Q0G

  • Illuminated pushbutton for easy visibility
  • IP65 front protection, durable in harsh conditions
  • Extended actuator with 1NO+1NC contact config
  • Mechanical life up to 5 million operations
  • Suitable for -20 to 55°C operating temp range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 250
Operating Voltage AC (V) 250
No. of Normally-open Contacts 1
No. of Normally-closed Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended
Bezel Material Plastic
Colour Green
Contact Configuration 1NO+1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type Without Lamp
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Momentary Extended - Without Lamp
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 250 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-M2E11Q0G is a green illuminated pushbutton designed for momentary action. It features a space-saving 10mm thick contact block and a removable operator for ease of use. The compact, lightweight design includes a durable metal bezel. Its separate contact block simplifies installation and maintenance procedures. This pushbutton is part of the versatile YW series, suitable for streamlined control panel designs.
