IDECYW1L-M2E10Q4R Illuminated Pushbutton 22mm Extended Momentary Red 24VAC/DC 1NO

Product Code: YW1L-M2E10Q4R

  • Illuminated pushbutton with built-in red LED
  • Durable with 5M ops single, 1M ops double block
  • IP65 front protection for harsh environments
  • Extended actuator type for easy operation
  • Operates at -20 to 55°C, ideal for various settings
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 24
Operating Voltage AC (V) 24
No. of Normally-open Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended
Bezel Material Plastic
Colour Red
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Red
Lamp Type Built-in LED
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Momentary Extended-LED Lamp
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 24 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-M2E10Q4R is a compact, illuminated pushbutton featuring a bright red LED for clear visibility. Its space-saving design includes 10mm thick contact blocks and a lightweight construction for ease of use. The removable operator and separate contact block ensure straightforward installation and maintenance. This momentary pushbutton is designed with a plastic bezel and is suitable for 24V AC/DC applications.
