Specifications

Mounting Hole Diameter (mm)	22
No. of Positions	2
Operational Temperature Range (°C)	-25 to +70
Weight (kg)	0.015
Storage Temperature (°C)	-40 to +85
Illuminated	Yes
Product Type	Selector Switch
Brand	ABB
Actuator Type	Short Handle
Bezel Material	Plastic
Colour	Green
Degree of Protection	IP66
Depth	50 mm
Function	Maintained
Height	30 mm
Illumination	Illuminated
Maintained Position	B, C
Material	Plastic
Mode of Operation	Maintained A, C
Mounting Hole Diameter	22 mm
NEMA Rating	NEMA 1, 12, 13, 3R, 4, 4X
Number of Positions	2
Operational Temperature	-25 to 70 deg C
Range	Modular plastic
Standards and Approvals	IEC/EN 60073, IEC/EN 60529, IEC/EN 60947-1, IEC/EN 60947-5-1, IEC/EN 60947-5-5
Storage Temperature	-40 to 85 deg C
Weight	0.015 kg
Width	30 mm
