IDECHW1L-M120D2A Illuminated Pushbutton 22mm Flush Momentary Amber 2NO

Product Code: HW1L-M120D2A

  • Illuminated pushbutton with amber colour
  • Durable with 5 million mechanical operations
  • IP65 front protection, suitable for harsh environments
  • Flush actuator design with a round plastic bezel
  • UL listed and CE marked for quality assurance
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 2NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Amber
Lamp Type Without Lamp
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-M120D2A is an illuminated momentary pushbutton featuring a flush operator and alternate action mechanism. This 110 V DC pushbutton comes with an amber light for clear visibility and includes a durable plastic bezel. Designed for quick and responsive operation, it provides dual normally open (2NO) contacts to suit various control circuit requirements.
