ABB E202125RD Switch Disconnector IP10 125A 2-P 230/400VAC DIN Rail Mount

Product Code: E202125RD

  • Compact size: 35mm width, 85mm height
  • Rated for 125A and 230/400VAC
  • Meets AS/NZS 60947-3 standards
  • DIN rail mountable for easy installation
  • Short circuit capacity of 6kA
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Busbar Cross Section (mm²) ≥ 16
Dimensions (mm) 85H x 69D x 35W
No. of Poles 2P
Pole Width (mm) 17.5
Power Loss (W) 6.1/Pole
Rated Conditional Short-Circuit Current - Inc (kA) 6
Rated Current (A) 125
Rated Frequency (Hz) 50/60
Rated Impulse Withstand Voltage (kV) 4
Rated Operational Voltage DC (V) 60
Rated Operational Voltage AC (V) 230/400
Poles 2P
Current Rating (A) 125
Family E200
AC Voltage (V) 230/400
DC Voltage (V) 60
Inc-Rated Conditional Short Circuit Capacity (kA) 6
Impulse Withstand Voltage (kV/1.2µS) 4
Minimum Operational Voltage AC (V) 12
Minimum Operational Voltage DC (V) 12
Product Type Switch Disconnector
Brand ABB
Series E200
Application Domestic
Bulbar Cross Section >=16 sq-mm
Colour RAL 7035 Light Grey
Contact Configuration 0NC+2NO
Degree of Protection IP10
Depth 69 mm
Height 85 mm
Housing Material Grey, RAL 7035
Mounting Type DIN Rail
Number of Poles 2
Pole Width 17.5 mm
Power Loss 6.1 W
Rated Current 125 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Voltage 230/400 VAC
Short Circuit Capacity 6 kA
Standards and Approvals AS/NZS 60947-3
Width 35 mm

Description

The ABB Switch Disconnector is a 2 Pole device with a current rating of 125A. It operates at a voltage of 230/400VAC and is designed for load break switching and isolation. This switch disconnector is part of the domestic range, making it suitable for residential applications.
