When it comes to safeguarding your electrical systems, the right surge protector can make all the difference. Designed for industrial and commercial applications, this surge protector offers robust protection with a focus on reliability and efficiency. Operating at a rated voltage of 24 VAC and supporting a current of up to 16 A, this device is engineered for those seeking dependable performance in demanding environments.
The unit features two phases and provides comprehensive protection across multiple modes: L1-L2, L1-PE, and L2-PE. Its response time is impressively swift at less than 5 nanoseconds between line-to-line (L-L) and line-to-earth (L-PE), ensuring your equipment remains secure during unexpected surges.
Designed for ease of installation, this surge protector mounts seamlessly onto a TS35 DIN rail. Its compact dimensions—18 mm wide, 69 mm high, and 115 mm deep—make it an ideal choice for space-conscious setups without compromising on functionality. The LED status display offers clear visual feedback on operational status, enhancing user convenience.
Built to withstand harsh conditions, the unit operates efficiently within a temperature range of -40 to 70 degrees Celsius while maintaining optimal performance under humidity levels ranging from 5% to 95%. With an IP20 degree of protection, it's well-suited for indoor applications where dust ingress needs to be minimized.
Safety standards are paramount in industrial settings; hence this product complies with IEC 61643-11, AS/NZS 1768, UL 1449, and IEEE 62.41.2 standards. These certifications underscore its credibility as a reliable component in any electrical setup.
Weighing just 150 grams yet constructed from durable aluminium material ensures that it not only performs well but also stands up to physical demands over time. The tightening torque required is minimal at just 0.5 N-m which simplifies installation procedures further reducing downtime during maintenance activities or initial setup phases alike!
Additionally equipped with two poles along with an integrated fuse rating matching its current capacity (16 A), users can rest assured knowing their systems have adequate backup should anything go awry unexpectedly due unforeseen circumstances beyond control like lightning strikes etcetera!
Finally boasting voltage protection level below threshold value (<160 V) coupled alongside rated short circuit current capability reaching heights upwards towards ten kiloamperes (10 kA); all these factors combined serve illustrate why choosing such protective measure becomes quintessential part overall strategy aimed preserving longevity expensive assets deployed across various sectors including but not limited manufacturing plants data centers telecommunications networks educational institutions healthcare facilities among others!
