Specifications

Dimensions (mm)	18W x 69H x 115D
Nominal Voltage AC (V)	48
Response Time (ns)	<100
Backup fuse rating (A)	6
Maximum Temperature (°C)	70
Minimum Temperature (°C)	-40
Weight (g)	350
Maximum Continuous Voltage DC (V)	65
Maximum Continuous Voltage AC (V)	50
Product Type	Surge Filter
Brand	NOVARIS
Degree of Protection	IP20
Depth	115 mm
Display Type	LED Power and Thermal Failure
Fuse Rating	6 A
Height	69 mm
Humidity	5-95%
Material	Aluminium
Modes of Protection	(+)-(-), (+)-PE, (-)-PE
Mounting Type	TS35 DIN Rail
Number of Poles	2
Number of Ports	2
Operational Temperature	-40 to 70 deg C
Phase	2
Rated Current	6 A
Rated Short Circuit Current	10 kA
Rated Voltage	48 VAC
Response Time	<100 ns
Tightening Torque	0.5 N-m
Voltage Protection Level	<130V (L-L), <130V (L-PE)
Weight	350 g
Width	18 mm
