ABB MPJA422 Illuminated Joystick Operator Switch Without Latching 240 V 22mm dia Mounting Hole 2NO+2NC

Product Code: MPJA422

  • Operates at 240V, 50/60 Hz
  • Illuminated pilot light head
  • Wide temp range: -25 to 70°C
  • IP20, IP66, IP67, IP69K ratings
  • Screw clamp connection
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 2NO+2NC
Sub-Function 4-Position
Actuating Direction Not Applicable
Bezel Material Plastic
Product Type Joystick Operator Switch Without Latching
Brand ABB
Actuator Type Pilot Light Head
Connecting Capacity 1 x 0.75-2.5 sq-mm Flexible, 2 x 0.75-2.5 sq-mm Flexible, 1 x 0.75-2.5 sq-mm Solid, 2 x 0.75-2.5 sq-mm Solid
Connection Type Screw Clamp
Degree of Pollution IP3
Degree of Protection IP20, IP66, IP67, IP69K
Function Maintained
Illumination Illuminated
Lamp Colour Clear
Lamp Type BA9S
Mode of Operation Maintained
NEMA Rating NEMA 1, 12, 13, 3R, 4, 4x
Operational Temperature -25 to 70 deg C
Rated Current 1 A, 1.5 A
Rated Frequency 50/60 Hz
Rated Voltage 240 V
Storage Temperature -40 to 85 deg C
Suitable For Use With 3 W Max Bulb
Terminal Type Screw
Tightening Torque 0.9 N-m
Weight 0.018 kg
Wire Stripping Length 8 mm

Description

This joystick kit is designed without a latching function. It has 4 positions and features 2 normally open (NO) and 2 normally closed (NC) maintained modular switches. The kit is made of black plastic and has front protection ratings of IP66, IP67, and IP69K.
